Siemens SIPART PS2 Compact Operating Instructions

SIPART PS2 (6DR5...)
A5E03436620-06, 04/2015
53
7.5.5 EMC filter module
Without Ex protection
With Ex protection Ex ia
With Ex protection
Ex "ic", "nA", "t"
EMC filter module type C73451-A430-D23 is required for NCS sensor or an external potentiometer.
External position sensor (potentiometer or NCS; option) with the following maximum values
Resistance of the external potentiometer 10 kΩ
Maximum values when powered by the
PROFIBUS basic device
- U
o
= 5 V
I
o
= 75 mA static
I
o
= 160 mA short-term
P
o
= 120 mW
U
o
= 5 V
I
o
= 75 mA
P
o
= 120 mW
Maximum values when powered by other
basic devices
- U
o
= 5 V
I
o
= 100 mA
P
o
= 33 mW
C
o
= 1 μF
L
o
= 1 mH
U
o
= 5 V
I
o
= 75 mA
P
o
= 120 mW
C
o
= 1 μF
L
o
= 1 mH
Galvanic isolation
Galvanically connected with the basic device
7.5.6 Non-contacting position sensor
Additional modules
Without Ex protection
With Ex protection
Ex "ia"
With Ex protection
Ex "ic", "nA"
Travel range
•
Linear actuator 6DR4004-.N.20
3 to 14 mm (0.12 to 0.55")
•
Linear actuator 6DR4004-.N.30
10 ... 130 mm (0.39 to 5.12"); up to 200 mm (7.87") on request
•
Part-turn actuator
30 ... 100°
Linearity (after corrections made by
positioner)
± 1 %
Hysteresis
± 0.2 %
Temperature influence (range:
rotation angle 120° or stroke
14 mm)
≤ 0.1 %/10 K (≤ 0.1 %/18 °F) for -20 to +90 °C (-4 to +194 °F)
≤ 0.2%/10 K (≤ 0.2%/18 °F) for -40 to -20 °C (-40 to -4 °F)
Climate class
According to DIN EN 60721-3
•
Storage
1K5, but -40 to +90 °C (-40 to +194 °F)
•
Transport
2K4, but -40 to +90 °C (-40 to +194 °F)
Vibration resistance
•
Harmonic oscillations
(sine) according to IEC 60068-
2-6
3.5 mm (0.14"), 2 to 27 Hz, 3 cycles/axis
98.1 m/s² (321.84 ft/s²), 27 to 300 Hz, 3 cycles/axis
• Bumping according to IEC
60068-2-29
300 m/s
2
(984 ft/s
2
), 6 ms, 4000 shocks/axis
Torque for cable gland nut made of
Plastic
Metal
Stainless steel
2.5 Nm (1.8 ft lb)
4.2 Nm (3.1 ft lb)
4.2 Nm (3.1 ft lb)
Housing protection type
IP68 according to IEC/EN 60529; NEMA 4X / Encl. Type 4X
For connecting to circuits with the
following peak values
- U
i
= 5 V
I
i
= 160 mA
P
i
= 120 mW
U
i
= 5 V
Effective internal capacitance
-
C
i
= 180 nF
C
i
= 180 nF
Effective internal inductance
-
L
i
= 922 μH
L
i
= 922 μH
Certificates and approvals
CE conformity The applicable directives and applied standards with their revision levels can be
found in the EC declaration of conformity on the Internet.
