Siemens SIRIUS Configuration Manual

Selection tables 500 V AC
4.3 Motor starter protector + contactor + 3RB3 solid-state overload relay
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
59
4.3 Motor starter protector + contactor + 3RB3 solid-state overload relay
Type of coordination 1,
short-circuit breaking capacity
I
q
= 100 kA
$
&9
Standard three-
phase motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Motor starter
protector
Starter protection
3)
Contactor
2)
Overload relay
(solid-state)
Setting range
Overload
release
Overload
relay
kW A
Setting
range
Overload
release
Motor
starter
protector
Order No. Order No.
Size
Order No. A
CLASS 10
0,04 0,11 0,2 3RV2311-0BC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1RB0 0,1 ... 0,40
0,06 0,16 0,2 3RV2311-0BC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1RB0 0,1 ... 0,40
0,09 0,24 0,32 3RV2311-0DC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1RB0 0,1 ... 0,40
0,12 0,32 0,4 3RV2311-0EC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1NB0 0,3 ... 1,25
0,18 0,48 0,63 3RV2311-0GC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1NB0 0,3 ... 1,25
0,25 0,68 0,8 3RV2311-0HC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1NB0 0,3 ... 1,25
0,37 0,88 1 3RV2311-0JC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1NB0 0,3 ... 1,25
0,55 1,20 1,25 3RV2311-0KC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1PB0 1,0 ... 4,00
0,75 1,50 1,6 3RV2311-1AC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1PB0 1,0 ... 4,00
1,1 2,20 2,5 3RV2311-1CC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1PB0 1,0 ... 4,00
1,5 2,90 3,2 3RV2311-1DC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1PB0 1,0 ... 4,00
2,2 3,90 5 3RV2311-1FC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1PB0 1,0 ... 4,00
2,2 3,90 5 3RV2311-1FC10 3RT2015-1AP01 S00/S00/S00 3RB3016-1PB0 1,0 ... 4,00
3 5,20 8 3RV2311-1HC10 3RT2016-1AP01 S00/S00/S00 3RB3016-1SB0 3,0 ... 12,00
4 6,80 8 3RV2311-1HC10 3RT2016-1AP01 S00/S00/S00 3RB3016-1SB0 3,0 ... 12,00
5,5 9,20 10 3RV2311-1JC10 3RT2017-1AP01 S00/S00/S00 3RB3016-1SB0 3,0 ... 12,00
7,5 12,40 16 3RV2321-4AC10 3RT2026-1AP00 S0/S0/S0 3RB3026-1QB0 6,0 ... 25,00
11 17,60 22 3RV2321-4CC10 3RT2026-1AP00 S0/S0/S0 3RB3026-1QB0 6,0 ... 25,00
15 23,00 32 3RV2321-4EC10 3RT2027-1AP00 S0/S0/S0 3RB3026-1VB0 10,0 ... 40,00
