SITOP PSU300S
Manual, 12.2016, C98130-A7587-A1-7-7629
35
Technical data
6
Note
Technical data apply for a rated input voltage, rated load and 25
°C ambient temperature if
nothing else is specified.
6.1
Input
6EP1433-2BA20
(24 V/5 A)
6EP1434-2BA20
(24 V/10 A)
6EP1436-2BA10
(24 V/20 A)
6EP1437-2BA20
(24 V/40 A)
Input
3-phase, AC
Rated voltage U
in rated
400 - 500 V
Voltage range
340 - 550 V
Wide-range input Yes
Line failure buffering at
I
out rated
, min
18 ms 7 ms 6 ms 6 ms
Power-failure buffering
At U
in
= 400 V
Rated line frequency
50 - 60 Hz
Line frequency range
47 - 63 Hz
Input current / at rated
value of input voltage
400 V
0.45 A 0.7 A 1.2 A 2 A
Input current / at rated
value of input voltage
500 V
0.4 A 0.6 A 1 A 1.7 A
Inrush current limiting
(25 °C), max.
20 A 20 A 36 A 60 A
I²t, max
0.5 A
2
s
0.5 A
2
s
0.9 A
2
s
3.4 A
2
s
Integrated input fuse
None
Protection in the line
feeder cable (IEC 898)
required: 3-pole, coupled miniature circuit
breaker 3 - 16 A characteristic C or circuit
breaker 3RV2011-1DA10 (setting 3 A) or
3RV2711-1DD10 (UL 489-listed, DIVQ)
required: 3-pole, cou-
pled miniature circuit
breaker 6 - 16 A char-
acteristic C or circuit
breaker 3RV2011-
1DA10 (setting 6 A) or
3RV2711-1DD10
(UL 489-listed, DIVQ)
required: 3-pole, cou-
pled miniature circuit
breaker
10 - 16 A characteris-
tic C or circuit breaker
3RV2011-1DA10 (set-
ting 3 A) or 3RV2711-
1DD10 (UL 489-listed,
DIVQ)
Overvoltage strength
-
-
2.3 × U
in rated
1.3 ms
-
