Technical data
6.7 Mechanical system
SITOP PSU300S
44 Manual, 12.2016, C98130-A7587-A1-7-7629
6.7
Mechanical system
6EP1433-2BA2
(24 V/5 A)
6EP1434-2BA20
(24 V/10 A)
6EP1436-2BA10
(24 V/20 A)
6EP1437-2BA20
(24 V/40 A)
Connection system
screw-type terminal
Connections / line
supply
L1, L2, L3, PE: 1 screw terminal each for 0.2 - 4 mm² solid/finely stranded
Connections / output +, -: 2 screw terminals each for 0.2 - 4 mm² +, -: 2 screw terminals
each for 0.5 - 10 mm²
Connections / auxiliary
contacts
(13, 14) (signal): 1 screw terminal each for 0.14 - 1.5 mm²
Width of the housing
50 mm
70 mm
90 mm
145 mm
Height of the housing
125 mm
125 mm
145 mm
145 mm
Depth of the housing
120 mm
120 mm
150 mm
150 mm
Installation width
50 mm
70 mm
90 mm
145 mm
Mounting height
225 mm
225 mm
225 mm
225 mm
Weight, approx.
0.5 Kg
0.7 Kg
1.6 kg
3.1 kg
Product feature of the
housing / housing that
can be lined up next to
one another
Yes
Type of mounting /
panel mounting
No
Type of mounting / rail
mounting
Yes
Type of mounting / S7-
300 rail mounting
No
Mounting Can be snapped onto standard TH35-15/7,5 (EN 60715) mounting rails Can be snapped onto
standard TH35-15
(EN 60715) mounting
rails
6.8
Accessories
6EP1433-2BA20 (24 V/5 A)
6EP1434-2BA20 (24 V/10 A)
6EP1436-2BA10 (24 V/20 A)
6EP1437-2BA20 (24 V/40 A)
Electrical accessories Redundancy module, buffer module, diagnostics module SITOP select (for
6EP1433-2BA20 only PSE200U) or DC USV
Mechanical accessories
Device identification labels 20 mm × 7 mm, pastel turquoise 3RT1900-1SB20
