10 GB/IE/NI/MT/CY
Wall mounting
C
[] [2] [1][]
m
WARNING! Risk of electric shock!
Do not drill into any pipes or mains cables
beneath the mounting surface. Use a voltage/
metal detector.
NOTES:
Mark the position of the 2 drill holes on the
wall through the screw holes [] of the wall
bracket [] (fig. C ).
Drill the 2 holes.
Insert the dowels [2] into the drill holes and
attach the wall bracket using the screws [1]
(fig. C ).
If you want to stick the product on a smooth
surface, remove the protective foil from the
adhesive tape on the back of the wall bracket
[] (fig. C ).
The arrow on the wall bracket must point
upwards (fig. C ).
The tampering alarm is deactivated as long as
the product is sitting in its wall bracket [].
If the product is removed from the wall bracket
[], the tamper alarm button [8] is triggered.
