104 73 97-26 S0100 / S0105 19
Right hand needle
Needle plate
Feed Dog
12. Feed timing
CHECK
Turn the hand wheel in the sewing direction and when the needle is going down set the tip
of right needle (A-needle) so its aligned with the surface of the needle plate, then should the
feed dog teeth be aligned with top surface of the needle plate.
ADJUSTMENT
1. Check so the basic feed cam setting is correct.
2. Turn hand wheel in sewing direction you so that the tip of the right needle (A-needle) is
aligned with the surface of the needle plate.
3. Loosen feed lifting cam screw (A) and adjust feed dog so that it is aligned with surface of
the needle plate.
4. Tighten screw (A).
A
