104 73 97-26
S0100 / S0105
27
20. Motor belt tension
CHECK
It should be possible to push down the belt 7~8 mm when applying a pressure of 0.5 kg.
ADJUSTMENT
1. Loosen screw (A) that is holds the motor
.
2.
Adjust belt tension by moving the motor back or forth
3. T
ighten the screw (A).
A
26
28
Table of Contents
Table of Contents
2
Cover Removal
3
Setting of Cams
6
Needle Bar Height
8
Needle Plate Sideways
9
Height of Lower Looper
10
Clearance between Lower Looper and Needle
11
End Position of Lower Looper
11
Timing of Lower Looper and Needle
12
Clearance between Lower Looper and Needles
13
Upper Looper Retainer Bracket
14
Setting of Upper Looper in Relation to the Needle
15
Timing of Upper Looper and Lower Looper
16
Clearance between Upper Looper and Lower Looper
17
Feed Dog Height
18
Feed Timing
19
Position of the Lower Knife
20
Position of Upper Knife against the Lower Knife
21
Clearance between Rear Needle Support and Needle
22
Clearance between Front Needle Support and Needle
23
Thread Height
24
Presser Foot Height
25
Stitch Width Fi Nger
26
Motor Belt Tension
27
Lengths Movement of Feed Dog in Needle Plate Slot
28
Stitch Lengths
29
