ACC4100 Diesel Air Compressor Controller User Manual Page 18 of 52
to the information; otherwise refer to engine user manual to obtain information according to SPN alarm code.
7 WIRE CONNECTION
Fig. 6 Controller Back Panel
Table 8 Connection Terminal Description
No.
Function
Cable
Size
Remark
1
DC Power Input B-
1.5mm
2
Connects starter battery negative;
2
DC Power Input B+
1.5mm
2
Connects starter battery positive;
3
COM1 Relay
1.5mm
2
Connects COM1 output, Rated 5A DC28V;
4
Crank Relay Output
1.0mm
2
5
AUX. Output 1
1.0mm
2
6
COM2 Relay
1.0mm
2
Connects COM2 output, Rated 1A DC28V;
Please
see
Table 10
for
setting
items.
7
AUX. Output 2
1.0mm
2
8
AUX. Output 3
1.5mm
2
9
AUX. Output 4
1.5mm
2
10
AUX. Output 5
1.0mm
2
N/O volts free contact, Rated 1A DC28V;
11
1.0mm
2
12
AUX. Output 6
1.0mm
2
N/O output, Rated 1A DC28V;
