ACC4100 Diesel Air Compressor Controller User Manual Page 48 of 52
14.12 MTU ADEC (SMART MODULE)
Suitable for MTU engine with ADEC (ECU8) and SMART module; Engine type: mtu-ADEC.
Table 32 ADEC (X1 Port)
Terminals of controller
ADEC (X1port)
Remark
Fuel relay output
X1 10
X1 Terminal 9 connected to negative of battery.
Starting relay output
X1 34
X1 Terminal 33 connected to negative of battery.
Table 33 ADEC (X4 Port)
Terminals of controller
SMART (X4 port)
Remark
CAN(H)
X4 1
Using impedance 120Ω connecting line.
CAN(L)
X4 2
Using impedance 120Ω connecting line.
14.13 MTU ADEC (SAM MODULE)
Suitable for MTU engine with ADEC (ECU7) and SAM module; Engine type: Common J1939.
Table 34 ADEC (X1 Port)
Terminals of controller
ADEC (X1port)
Remark
Fuel relay output
X1 43
X1 Terminal 28 connected to negative of battery.
Starting relay output
X1 37
X1 Terminal 22 connected to negative of battery.
Table 35 SAM (X23 Port)
Terminals of controller
SAM (X23 port)
Remark
CAN(H)
X23 2
Using impedance 120Ω connecting line.
CAN(L)
X23 1
Using impedance 120Ω connecting line.
14.14 PERKINS
Suitable for ADEM3/ADEM4 engine control module; Engine model is 2306, 2506, 1106, and 2806.
Engine type: Perkins.
Table 36 Connector
Terminals of controller
Connector
Remark
Fuel relay output
1, 10, 15, 33, 34
Starting relay output
-
Connect to starter coil directly.
CAN(H)
31
Using impedance 120Ω connecting line.
CAN(L)
32
Using impedance 120Ω connecting line.
