Smartgen ACC4100 User Manual

ACC4100 Diesel Air Compressor Controller User Manual Page 8 of 52
3 SPECIFICATION
Table 3 Technical Parameters
Items
Contents
Operating Voltage
DC8.0V~35.0V, continuous power supply
Power Consumption
<3W (Standby mode: ≤2W)
Speed Sensor Voltage
1.0V~24.0V (RMS)
Speed Sensor Frequency
Max. 10, 000Hz
Charging Generator W/L
Voltage (1.0-24.0)V (RMS) Frequency (50-1,000)Hz
Starting Relay Output
5A DC28V
Programmable Output 1
5A DC28V
Programmable Output 2~6
1A DC28V
Analog Sensor
3 ways of fixed resistance type (fuel level, programmable sensor 1,
programmable sensor 2);
3 ways of flexible resistance/current/voltage types (discharge pressure,
programmable sensor 3, programmable sensor 4);
Case Dimensions
135mm x 110mm x 44mm
Panel Cutout
116mm x 90mm
Working Conditions
Temperature: (-25~+70)°C; Humidity: (20~93)%RH
Storage Condition
Temperature: (-25~+70)°C
Protection Level
IP65 front panel
Weight
0.35kg
