ACC4100 Diesel Air Compressor Controller User Manual Page 36 of 52
8.4 SELECTION OF SENSORS
Table 12 Sensors Selection
No.
Items
Description
Remark
1
Temperature Sensor
0 Not used
1 Custom Res Curve
2 Custom (4-20)mA Curve
3 Custom Volt Curve
4 VDO
5 CURTIS
6 VOLVO-EC
7 DATCON
8 SGX
9 SGD
10 SGH
11 PT100
12 Cu50
13-15 Reserved
Defined resistance’s range is
(0~1)kΩ, default is “Not Used”;
Users can select the
corresponding curve by
themselves;
If pre-set sensor channel
doesn't support current, and
voltage type, then curve type
item 2 and 3 display
“Reserved”.
2
Oil Pressure Sensor
0 Not used
1 Custom Res Curve
2 Custom (4-20)mA Curve
3 Custom Volt Curve
4 VDO 10bar
5 CURTIS
6 VOLVO-EC
7 DATCON 10bar
8 SGX
9 SGD
10 SGH
11 -15 Reserved
Defined resistance’s range is
(0~1)kΩ, default is “Not Used”;
Users can select the
corresponding curve by
themselves;
If pre-set sensor channel
doesn't support current, and
voltage type, then curve type
item 2 and 3 display
“Reserved”.
3
Fuel Level Sensor
0 Not used
1 Custom Res Curve
2 Custom (4-20)mA Curve
3 Custom Volt Curve
4 SGD
5 SGH
6 -15 Reserved
Defined resistance’s range is
(0~1)kΩ, default is “Not Used”;
Users can select the
corresponding curve by
themselves;
If pre-set sensor channel
doesn't support current, and
voltage type, then curve type
item 2 and 3 display
“Reserved”.
