Smartgen ACC4100 User Manual

ACC4100 Diesel Air Compressor Controller User Manual Page 49 of 52
14.15 SCANIA
Suitable for S6 engine control module; Engine model is DC9, DC12, and DC16. Engine type: Scania.
Table 37 B1 Connector
Terminals of controller
B1 connector
Remark
Fuel relay output
3
Starting relay output
-
Connect to starter coil directly.
CAN(H)
9
Using impedance 120Ω connecting line.
CAN(L)
10
Using impedance 120Ω connecting line.
14.16 VOLVO EDC3
Suitable engine control mode is TAD1240, TAD1241, and TAD1242; Engine type: Volvo.
Table 38 “Stand alone” Connector
Terminals of controller
“Stand alone” connector
Remark
Fuel relay output
H
Starting relay output
E
Programmable output 1
P
ECU power;
Set configurable output 1 “ECU power”.
Table 39 “Data Bus” Connector
Terminals of controller
“Data bus” connector
Remark
CAN(H)
1
Using impedance 120Ω connecting line.
CAN(L)
2
Using impedance 120Ω connecting line.
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
14.17 VOLVO EDC4
Suitable engine models are TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721, TAD722,
and TAD732. Engine type: Volvo-EDC4.
Table 40 Connector
Terminals of controller
Connector
Remark
Fuel relay output
Expansion 30A relay,
providing battery voltage
for terminal 14; Fuse is
16A.
Starting relay output
-
Connect to starter coil directly.
1
Connected to negative of battery.
CAN(H)
12
Using impedance 120Ω connecting line.
CAN(L)
13
Using impedance 120Ω connecting line.
