HGM6100LT Series Genset Controller User Manual Page 15 of 50
5.2 SHUTDOWN ALARM
When controller detects shutdown alarm, it will send signal to open switch and stop genset. The
alarms are displayed in LCD.
Table 5 – Shutdown Alarms
No.
Items
Description
1
Emergency Stop
When controller detects emergency stop signal, it will send a shutdown
alarm signal and it will be displayed in LCD.
2
High Temp.
When the temperature of water/cylinder is higher than set threshold,
controller will send a shutdown alarm signal and it will be displayed in
LCD.
3
Low Oil Pressure
When oil pressure is lower than threshold, controller will send a
shutdown alarm signal and it will be displayed in LCD.
4
Over Speed
When genset speed is higher than set threshold, controller will send a
shutdown alarm signal and it will be displayed in LCD.
5
Under Speed
When genset speed is lower than set threshold, controller will send a
shutdown alarm signal and it will be displayed in LCD.
6
Loss of Speed Signal
When speed is 0 and delay is not 0, controller will send a shutdown
alarm signal and it will be displayed in LCD.
7
Gen Over Voltage
When genset voltage is higher than threshold, controller will send a
shutdown alarm signal and it will be displayed in LCD.
8
Gen Under Voltage
When genset voltage is under set threshold, controller will send a
shutdown alarm signal and it will be displayed in LCD.
9
Gen Over Current
When genset current is higher than set threshold and delay is not 0, it
will send a shutdown alarm signal and it will be displayed in LCD.
10
Failed to Start
Within set start times, if failed to start, controller will send a shutdown
alarm signal and it will be displayed in LCD.
11
Gen Over Freq.
When genset frequency is higher than set threshold, controller will send
a shutdown alarm signal and it will be displayed in LCD.
12
Gen Under Freq.
When genset frequency is lower than set threshold, controller will send a
shutdown alarm signal and it will be displayed in LCD.
13
No Gens
When genset frequency is 0, controller will send a shutdown alarm signal
and it will be displayed in LCD.
14
Low Fuel Level
When low fuel level input is active, controller will send a shutdown alarm
signal and it will be displayed in LCD.
15
Low Coolant Level
When genset coolant level low input is active, controller will send a
shutdown alarm signal and it will be displayed in LCD.
16
Temp. Sensor Open
When sensor hasn’t connected to corresponding port, controller will
send shutdown alarm signal and it will be displayed in LCD.
17
OP Sensor Open
When sensor hasn’t connected to corresponding port, controller will
send shutdown alarm signal and it will be displayed in LCD.
18
Maintenance Due
Maintenance type is running time. When genset running time is longer
