HGM6100LT Series Genset Controller User Manual Page 46 of 50
13.12 MTU ADEC (SMART MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 29 – ADEC (X1 port)
Terminals of controller
ADEC (X1 port)
Remark
Programmable output 1
X1 10
Set programmable output 1 as “Fuel
Output”.
X1 Terminal 9 Connected to negative of
battery.
Starting relay output
X1 34
X1 Terminal 33 Connected to negative of
battery.
Table 30 – SMART (X4 port)
Terminals of controller
SMART (X4 port)
Remark
CAN_SCR
X4 3
CAN communication shielding line.
CAN(H)
X4 1
Using impedance 120Ω connecting line.
CAN(L)
X4 2
Using impedance 120Ω connecting line.
Engine type: MTU-ADEC.
13.13 MTU ADEC (SAM MODULE)
It is suitable for MTU engine with ADEC (ECU7) and SAM module.
Table 31 – ADEC (X1 port)
Terminals of controller
ADEC (X1 port)
Remark
Programmable output 1
X1 43
Set programmable output 1 as “Fuel
Output”.
X1 Terminal 28 Connected to negative of
battery.
Starting relay output
X1 37
X1 Terminal 22 Connected to negative of
battery.
Table 32 – SAM (X23 port)
Terminals of controller
SAM (X23 port)
Remark
CAN_SCR
X23 3
CAN communication shielding line.
CAN(H)
X23 2
Using impedance 120Ω connecting line.
CAN(L)
X23 1
Using impedance 120Ω connecting line.
Engine type: Common J1939.
