HGM6100LT Series Genset Controller User Manual Page 36 of 50
10 COMMISSIONING
Before operation, the following checking should be carried out:
— Check and ensure all the connections are correct and wires diameter is suitable.
— Ensure that the controller DC power has fuse; starting battery positive and negative have
correctly connected.
— Emergence stop input must be connected to positive of starting battery via normally close
contact of emergency stop.
— Take proper actions to prevent engine to disconnect crank (e. g. Remove the connections of
fuel value). If checking is OK, connect start battery, select Manual Mode, controller will
execute the program.
— Set controller as Manual Mode, press “start” button to start genset. If failed within the setting
crank times, controller will send “Failed to Start” signal; then press “stop” to reset controller.
— Recover actions of preventing engine to disconnect crank (e. g. Connect wire of fuel value),
press “start” button again, genset will start. If everything goes well, genset will normal run
after idle running (if configured). During this period, watch for engine’s running situations and
voltage and frequency of alternator. If there is abnormal, stop genset and check all
connections according to this manual.
— Select the Auto Mode from front panel, connect to mains signal. After the mains normal delay,
controller will transfer ATS (if configured) into mains load. After cooling, controller will stop
genset and into standby state until mains abnormal again.
— When mains abnormal again, genset will start automatically and into normal running, send
signal to make gens close, transfer ATS and make genset take load. If it not likes this, please
check connections of ATS according to this manual.
— If there are any other questions, please contact SmartGen’s service.
