HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 53 of 60
Table 26 D-SUB Connector 06
Terminals of controller
D-SUB connector 06
Remark
RS485 GND
20
CAN communication shielding
line(connected with ECU
terminal only);
RS485+
21
Using impedance 120Ω
connecting line;
RS485-
18
Using impedance 120Ω
connecting line;
Engine type: Cummins QSK-MODBUS, Cummins QST-MODBUS, Cummins QSX-MODBUS.
16.6 CUMMINS QSM11
Table 27 Engine OEM Connector
Terminals of controller
OEM connector of engine
Remark
Aux. output port 1
38
Set it as “fuel output”;
Start relay output
-
Connected with starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
46
Using impedance 120Ω connecting line;
CAN(L)
37
Using impedance 120Ω connecting line;
Engine type: Common J1939.
16.7 CUMMINS QSZ13
Table 28 Engine OEM Connector
Terminals of controller
OEM connector of engine
Remark
Aux. output port 1
45
Start relay output
-
Connected to starter coil directly;
Aux. output 2
16&41
Set as idling speed control; (N/C) output; by
expansion relay, make 16&41 close as the
controller is running.
Aux. output 3
19&41
Set as pulse speed raising control; (N/O)
output; by expansion relay, make 19&41
close for 1s as the controller is entering
warming-up time.
CAN_SCR
-
CAN communication shielding line;
CAN(H)
1
Using impedance 120Ω connecting line;
CAN(L)
21
Using impedance 120Ω connecting line;
Engine type: Common J1939.
16.8 DETROIT DIESEL DDEC III/IV
