HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 57 of 60
Table 41 Connector
Terminals of controller
Connector
Remark
Aux. output port 1
Expansion 30A relay,
providing battery voltage for
terminal 14. Fuse is 16A.
Set it as “fuel output”;
Start relay output
-
Connected to starter coil directly;
1
Connected to negative of battery;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
12
Using impedance 120Ω connecting line;
CAN(L)
13
Using impedance 120Ω connecting line;
Engine type: Volvo EDC4.
16.18 VOLVO-EMS2
Volvo Engine types are TAD734, TAD940, TAD941, TAD1640, TAD1641, and TAD1642.
Table 42 Engine CAN Port
Terminals of controller
Engine’s CAN port
Remark
Aux. output 1
6
Set output 1 “ECU stop”;
Aux. output 2
5
Set output 2 “ECU power”;
3
Power negative;
4
Power passive;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
1(Hi)
Using impedance 120Ω connecting line;
CAN(L)
2(Lo)
Using impedance 120Ω connecting line;
Engine type: Volvo-EMS2.
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
16.19 YUCHAI
It is suitable for BOSCH common rail pump engine.
Table 43 Engine 42-Pin Port
Terminals of controller
Engine 42 pins port
Remark
Aux. output port 1
1.40
Set it as “fuel output”;
Connected to engine ignition lock;
Start relay output
-
Connected to starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
1.35
Using impedance 120Ω connecting line;
CAN(L)
1.34
Using impedance 120Ω connecting line;
Table 44 Engine 2-Pin Port
Battery
Engine 2 pins
Remark
Battery negative
1
Wire diameter 2.5mm
2
;
Battery positive
2
Wire diameter 2.5mm
2
;
Engine type: BOSCH.
