HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 54 of 60
Table 29 Engine CAN Port
Terminals of controller
CAN port of engine
Remark
Aux. output port 1
Expansion 30A relay,
proving battery voltage for
ECU;
Set it as “fuel output”;
Start relay output
-
Connected to starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
CAN(H)
Using impedance 120Ω connecting line;
CAN(L)
CAN(L)
Using impedance 120Ω connecting line;
Engine type: Common J1939.
16.9 DEUTZ EMR2
Table 30 F Connector
Terminals of controller
F connector
Remark
Aux. output port 1
Expansion 30A relay,
proving battery voltage for
14; Fuse is 16A.
Set it as “fuel output”;
Start relay output
-
Connected to starter coil directly;
-
1
Connected to battery negative;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
12
Impedance 120Ω connecting line is
recommended.
CAN(L)
13
Impedance 120Ω connecting line is
recommended.
Engine type: Volvo EDC4.
16.10 JOHN DEERE
Table 31 21-Pin Connector
Terminals of controller
21 pins connector
Remark
Aux. output port 1
G, J
Set it as “fuel output”;
Start relay output
D
CAN_SCR
-
CAN communication shielding line;
CAN(H)
V
Using impedance 120Ω connecting line;
CAN(L)
U
Using impedance 120Ω connecting line;
Engine type: John Deere.
