SMC-EZ1026DT V.2
27
5. Product Specifications
This section provides the specifications of SMC-EZ1026DT V.2
Switch, and the following table lists them.
Standards Compliance
IEEE802.3 10BASE-T
IEEE802.3u 100BASE-TX and 100BASE-FX
IEEE802.3ab 1000BASE-T
IEEE802.3z 1000BASE-SX/LX
IEEE802.3x Flow Control
Protocol CSMA/CD
Media Connector Basic unit: 24 RJ-45 for STP or UTP,
Auto MDI/MDI-X Support
100M FX Module: SC, MTRJ, VF45
Gigabit SX/LX Module: 1 Duplex SC
Gigabit 1000T Module: 1 RJ-45 for UTP or STP,
Auto MDI/MDI-X Support
GBIC: Mini GBIC LC type, Standard GBIC SC type
Transfer Rate 14880 Packets per second for 10Mbps
148800 packets per second for 100Mbps
1488000 packets per second for 1000Mbps
Backplane Bandwidth 9.6Gbps
Switch Technology Store-and-Forward Error Free Packet Forwarding
Scheme
Supports Hardware Level Broadcast Storm
Prevention without Consuming System CPU
Utilization
MAC Address 8K MAC address with auto learning function
Data Buffer 6Mbits share memory
LED System Power, per port Link/active,
FDX/Col,10/100Mbps
Dimension 440mm(W)*225mm(D)*44.5mm(H)
Power 100~240 VAC 50/60HZ
EMI & Safety FCC Class A, CE, UL
