SMC Networks HRR012-A*-20 Series Operation Manual

HRX-OM-W004
Chapter 3 Serial communication
HRR Series 3.13 Register Map
3-19
3.13.1 Circulating fluid discharge temperature
Read the circulating fluid discharge temperature in the selected temperature
unit (°C or °F). Read the circulating fluid discharge temperature which is
displayed on the operation display panel. (Offset temperature is displayed if
offset function is set).
3.13.2 Circulating fluid flow rate
Read the circulating fluid flow rate in the selected pressure unit.
3.13.3 Circulating fluid discharge pressur
Read the circulating fluid discharge pressure in the selected pressure unit.
3.13.4 Electric conductivity of the circulating fluid
Electric conductivity of the circulating fluid is informed.
0 is announced when option-DM is not selected.
3.13.5 Status flag
The status of the product is read by the following assignment.
Status flag
Name Status flag
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit Name Explanation
0
Run flag
Run status 0= Stop 1= Run
1
Operation stop alarm flag
Operation stop alarm given off status
0= Not occurred 1= Operation stop alarm given off
2
Operation continued alarm
flag
Operation continued alarm given off status
0= Not occurred 1= Operation continued alarm
given off
3
Unused
―
4
Unused
―
5
Remote status flag
Remote status
0= Other than SERIAL mode 1= SERIAL mode
6
Unused
―
7
Unused
―
8
Unused
―
9
Completion of preparation
(TEMP READY) flag
Completion of preparation (TEMP READY) status
0= Condition isn’t formed 1= Condition is formed
10
Temperature range
monitoring
（TEMP OUT）flag
Temperature range monitoring(TEMP OUT) status
0= Condition is not established
1=Condition is established
11
Notice for maintenance
Notice for maintenance status
0 = Not generated 1 = Generated
12
Unused
―
13
Unused
―
14
Unused
―
15
Unused
―
