PTE-100-C
5
PTE-100-C PACKING LIST
1 PTE-100-C unit
1 Nylon bag
1 AC supply cord
6 2-meter, 2.5 mm
2
section test leads (3 black, 3 red)
2 2-meter, 10 mm
2
section test leads (1 black, 1 blue)
1 2-meter RS-232 communications cable to PC
2 6-mm to 4-mm plug adapters
4 Clips up to 50A (2 black, 2 red)
4 Clips up to 10A (2 black, 2 red)
2 5 x 20 mm, 100 mA, FAST fuses
2 5 x 20 mm, 0.5 A, Standard fuses
1 Calibration Software CD-ROM
2 Case Key
1 Warranty Registration Form
1 Measurements Certificate
1 This user’s manual
USER’S MANUAL
6
INTRODUCTION
The PTE-100-C Relay Test Set is designed to test protective relays based on
single-phase current and /or voltage measurement.
Its small size, excellent output power and accuracy, quality features, and
ease of use, make this product one of the best choices available in its kind.
To achieve this goal, EUROSMC collected the opinion and suggestions of
various professionals and companies of recognized prestige and experience
in protective relay maintenance and commissioning. As a result, the PTE-
100-C features the following unique characteristics:
Robust mechanical and electrical construction.
Great portability.
Built-in measurement features to avoid carrying a large number of
instruments.
Results printout capability, when taking notes is usually difficult.
Software-assisted closed-case calibration with a Windows PC.
Functions to protect the relay being tested.
Easy, intuitive operation.
The PTE-100-C includes all the accessories needed for testing, such as ca-
bles, clips, nylon bag for transport, spare fuses etc. as standard equipment.
We appreciate your suggestions about the PTE-100-C and this manual, in
our commitment to improve our quality. Our technical staff will be pleased
to help you on any difficulties or questions that you may have.
Thank you for choosing EuroSMC products.
EUROSMC, S.A.
Pol. Ind. P-29 Calle Buril 69
28400 Collado Villalba. MADRID (SPAIN)
TEL: 34-91-91 849 89 80. FAX: 34-91-851 25 53
www.eurosmc.com
