11
EN
STATYS XS - IOMSTAXS1217-EN_04 - SOCOMEC
4.2. LCD
A B
A
B
L
V
A
Hz
%
Symbol Description/function
Input A error or power failure
Input B error or power failure
Overload
System malfunction or abnormal
Alarm on
Alarm off
Digital display showing input/output power
connected to load
Statys XS numeric display
A
B
