socomec Statys XS series User Manual

18
EN
STATYS XS - IOMSTAXS1217-EN_04 - SOCOMEC
9. SYSTEM SPECIFICATIONS
Model STAYS XS 16A STAYS XS 32A
Input
Input voltage
200/208/220/230/240V
230V factory setting +/-10% (configurable +/-5% to +/-20%)
Input voltage range 180Vac - 264Vac
Input frequency
50 / 60Hz
+/-10% (configurable +/-5% to +/-20%)
Output
Output voltage Equal to Input
Rated Output current
16A 32A
Can be congured to lower current for alarm management
Protection Electronic circuit and upstream protections
Transfer time(ms) ITIC curve compliant
Admitted overload 125% / 1 minutes, 150% / 30 seconds
Connection
Input IEC C20 x 2 50A terminal 1 x 6P 10mm²
output
1 x IEC C19 (max. 16A)
8 x IEC C13 (max. 10A)
2 x IEC C19 (max. 16A)
16 x IEC C13 (max. 10A)
Communication 5 Dry contacts
Communication (option card) SNMP o r RS-485
Port for system access RS 232 / USB
Display LCD+LED
Physical
Dimension W x D x H (mm) 440 x 285 x 44 440 x 360 x 88
Net Weight (kgs) 4 6
Environment
Working temperature -5 to 40°C @ 5 to 90% RH (non-condensing)
Standards
compliance
Safety
EN 60950-1
EMC
EN 62310-2
