Top Page > Basic Operations > How to Use the i-Manual
How to Use the i-Manual
Searching for Information
This i-Manual explains how to use the TV's functions. On the main page of the i-Manual, you can
select the desired method to search for information.
1. Table of Contents: Searches from a title list.
2. Troubleshooting: Searches for solutions to problems.
3. Index: Searches by function/feature name.
Select from the / / tabs.
Tips
The supplied paper manual contains important information such as cautions and
operating instructions to prevent accidents. Read the supplied paper manual
thoroughly for safe use.
Steps
Procedure example: “Table of Contents” search
1. In the main page of this manual, highlight the “Table of Contents” tab using the / buttons.
(When using the Touchpad Remote Control, slide left/right.)
2. Highlight a title on the left of the screen using the / buttons, then press the button to
select.
(When using the Touchpad Remote Control, slide up/down to highlight a title, then press the
touchpad to select.)
The titles on the right side of the screen change according to the title selected on the left side of
the screen.
3. Highlight a title on the right side of the screen using the / buttons, then press the button
to select.
(When using the Touchpad Remote Control, slide up/down to highlight a title, then press the
touchpad to select.)
The page of the selected title appears.
4. Press the button to proceed to the next page.
To return to the previous page, press the button.
(When using the Touchpad Remote Control, slide left/right.)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony Bravia KD-65X9005B and is the answer not in the manual?

Sony Bravia KD-65X9005B Specifications

General IconGeneral
Product colorBlack
LED indicatorsYes
Panel mounting interface400 x 300 mm
Screen shapeFlat
Response time- ms
Display diagonal65 \
Display brightness- cd/m²
Native aspect ratio16:9
LED backlighting type-
Supported video modes1080i, 1080p, 2160p, 480i, 480p, 576i, 576p, 720p
Contrast ratio (dynamic)1000000:1
Display diagonal (metric)164 cm
Supported graphics resolutions3840 x 2160, 4096 x 2160, 1920 x 1080 (HD 1080)
Motion interpolation technologyMotionflow XR 800 Hz
3D glasses quantity2
Supported file systemsexFAT, FAT16, FAT32, NTFS
Annual energy consumption250 kWh
Tuner typeAnalog & digital
Digital signal format systemDVB-C2, DVB-S2, DVB-T2
Smart modesAnimation, Cinema, Custom, Game, Personal, Photo, Sports, Standard, Vivid
Lifestyle appsSkype
Sound modesMovie, Music, Standard
Audio decodersDolby Digital, Dolby Digital Plus, Dolby Digital Pulse
RMS rated power65 W
PC in (D-Sub)No
DVI-D ports quantity0
USB 2.0 ports quantity3
Component video (YPbPr/YCbCr) in1
Consumer Electronics Control (CEC)BRAVIA Sync
Browser supportedOpera
Audio formats supportedLPCM, MP3, WMA
Image formats supportedJPG, MPO
Video formats supported3GPP, AVCHD, AVI, MKV, MOV, MP4, MPEG1, MPEG2, WEBM, WMV, XVID
Power consumption (max)339 W
Power consumption (standby)0.3 W
Power consumption (typical)180 W
Package depth222 mm
Package width1813 mm
Package height976 mm
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)320 mm
Width (with stand)1716 mm
Height (with stand)916 mm
Weight (with stand)46600 g
Depth (without stand)99 mm
Width (without stand)1715 mm
Height (without stand)878 mm
