Sony BVM-D14H5U User Manual

55 (E)
Chapter 3 Appendix
Connection cable for PHILIPS PM 5639 probe (corresponds to PHILIPS PM 5639/64
cable)
Modular connector Mini DIN 8-pin connector
(male)
+5V
N.C.
RXD
TXD
N.C.
GND
1
2
3
4
5
6
NC
NC
RTS
GND
N.C.
TXD
+5V
RXD
1
2
3
4
5
6
7
8
16
1
2
3
6
8
5
Connection cable for THOMA TF6 probe
D-sub 15-pin connector (female) Mini DIN 8-pin connector (male)
Signal Pin Number
Signal Pin Number
Signal Pin Number
Signal Pin Number
N.C.
RXD
TXD
N.C.
N.C.
N.C.
GND
N.C.
1
2
3
4
5
6
7
8 to 15
NC
NC
RTS
GND
N.C.
TXD
+5V
RXD
1
2
3
4
5
6
7
8
18
915
1
2
3
6
8
5
