CDX-MP40
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7. ELECTRICAL PARTS LIST
MAIN
A-3274-836-A MAIN BOARD, COMPLETE (including
SPEAKER BOARD)
*********************
* 3-040-998-01 BRACKET (IC)
3-041-261-11 BRACKET (TR)
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C101 1-136-154-00 FILM 0.012uF 5% 50V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C109 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C201 1-136-154-00 FILM 0.012uF 5% 50V
C202 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C208 1-104-942-11 ELECT 1uF 20% 50V
C209 1-104-942-11 ELECT 1uF 20% 50V
C210 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C211 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C212 1-104-942-11 ELECT 1uF 20% 50V
C213 1-104-942-11 ELECT 1uF 20% 50V
C215 1-124-233-11 ELECT 10uF 20% 16V
C401 1-128-428-11 ELECT 10uF 20% 35V
C402 1-128-428-11 ELECT 10uF 20% 35V
C403 1-128-428-11 ELECT 10uF 20% 35V
C404 1-128-428-11 ELECT 10uF 20% 35V
C405 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C406 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C407 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C408 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C409 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C411 1-124-233-11 ELECT 10uF 20% 16V
C412 1-128-428-11 ELECT 10uF 20% 35V
C413 1-136-177-00 MYLAR 1uF 5% 50V
C415 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C416 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C417 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C418 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C419 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C420 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C421 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C423 1-104-942-11 ELECT 1uF 20% 50V
C424 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C425 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C426 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C427 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C428 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C429 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-124-259-11 ELECT 4.7uF 20% 16V
C505 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C506 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C507 1-124-589-11 ELECT 47uF 20% 16V
C614 1-124-584-00 ELECT 100uF 20% 10V
C615 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C616 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C617 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C618 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C621 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C622 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C623 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C624 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C629 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C701 1-124-589-11 ELECT 47uF 20% 16V
C702 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C703 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C704 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C705 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C712 1-124-584-00 ELECT 100uF 20% 10V
C713 1-124-584-00 ELECT 100uF 20% 10V
C714 1-124-584-00 ELECT 100uF 20% 10V
C715 1-128-057-11 ELECT 330uF 20% 6.3V
C716 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C717 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C718 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C719 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C803 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C804 1-126-940-11 ELECT 330uF 20% 16V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-125-710-11 DOUBLE LAYERS 0.1F 5.5V
C807 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C808 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C809 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C810 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Abbreviation
CND: Canadian model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
