Ref. No. Part No. Description Ref. No. Part No. Description
DCR-HC39E/HC41/HC42/HC42E/HC43/HC43E
FP-467 FP-826 JK-278 LB-109 MS-249
1-686-798-11 FP-467 FLEXIBLE BOARD
********************
(S902 is not included in this flexible board.)
< SWITCH >
S902 1-477-679-11 ROTARY, ENCODER (SWITCH) (MODE SWITCH)
(Not supplied) FP-826 FLEXIBLE BOARD
********************
(This flexible board is included in LS BLOCK
ASSY (A-7095-951-A).)
< DIODE >
D901 6-500-652-01 DIODE GL453SE0000F (TAPE LED)
< HOLL ELEMENT >
H901 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (S REEL)
H902 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (T REEL)
< CONNECTOR >
MIC902 1-817-175-12 PIN, CONNECTOR (WITH DELCTION SWITCH)
< TRANSISTOR >
Q901 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE END)
Q902 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE TOP)
< SWITCH >
S903 1-529-566-51 SWITCH, PUSH (1 KEY) (C.C. DOWN)
A-1081-841-A JK-278 BOARD, COMPLETE
**********************
< CONNECTOR >
CN701 1-815-794-21 CONNECTOR (MULTIPLE) (AV OUT: HC39E)
(AV: EXCEPT HC39E)
CN704 1-818-087-31 CONNECTOR, FFC/FPC (LIF) 26P
< DIODE >
D705 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D706 6-500-044-01 DIODE DF6A6.8FU (TE85R)
D707 6-500-044-01 DIODE DF6A6.8FU (TE85R)
< FERRITE BEAD >
FB701 1-400-823-11 EMI FERRITE (SMD) (1005)
FB702 1-400-823-11 EMI FERRITE (SMD) (1005)
FB703 1-400-823-11 EMI FERRITE (SMD) (1005)
< JACK >
J701 1-793-995-11 JACK, SUPER SMALL TYPE (LANC)
< RESISTOR >
R705 1-218-990-11 SHORT CHIP 0
R706 1-218-990-11 SHORT CHIP 0
R707 1-218-990-11 SHORT CHIP 0
R709 1-218-990-11 SHORT CHIP 0
A-1081-845-A LB-109 BOARD, COMPLETE (HC39E)
A-1081-846-A LB-109 BOARD, COMPLETE (EXCEPT HC39E)
**********************
< CAPACITOR >
C301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C302 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C303 1-164-505-11 CERAMIC CHIP 2.2uF 16V
< CONNECTOR >
CN301 1-818-046-11 FFC/CONNECTOR, FPC (LIF (NON-ZIF)) 20P
CN302 1-784-420-11 CONNECTOR, FFC/FPC (ZIF) 21P
< DIODE >
D302 6-500-941-01 DIODE MAZS056008S0
D303 6-500-874-01 DIODE E1S35-AW0C7-01-A2 (BACKLIGHT)
(HC39E)
D303 8-719-082-33 DIODE NSCW100-T38 (BACKLIGHT)
(EXCEPT HC39E)
< RESISTOR >
R302 1-216-841-11 METAL CHIP 47K 5% 1/10W
R303 1-218-971-11 RES-CHIP 33K 5% 1/16W
R304 1-218-975-11 RES-CHIP 68K 5% 1/16W
R305 1-218-989-11 RES-CHIP 1M 5% 1/16W
A-1081-843-A MS-249 BOARD, COMPLETE
***********************
< BATTERY >
0 BT501 1-756-075-21 BATTERY, LITHIUM (SECONDARY)
< CONNECTOR >
* CN501 1-691-378-21 CONNECTOR, FFC/FPC 14P
CN502 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN503 1-817-913-41 MEMORY STICK DUO CONNECTOR
< DIODE >
D501 6-500-817-01 DIODE SML-512UWT86 (MS ACCESS)
D503 6-500-776-01 DIODE MAZW068H0LS0
< RESISTOR >
R501 1-218-949-11 RES-CHIP 470 5% 1/16W
< SWITCH >
S501 1-771-138-82 SWITCH, KEY BOARD (RESET)
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
