5-13
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-HC39E/HC41/HC42/HC42E/HC43/HC43E
A-1081-853-A PD-238 BOARD, COMPLETE
**********************
< CAPACITOR >
C602 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C603 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C606 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C608 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C610 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C611 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C612 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C614 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C615 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C616 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C617 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C618 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C622 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C623 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C624 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C625 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C626 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C627 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C631 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C633 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN601 1-815-031-11 FFC/CONNECTOR, FPC (ZIF) 24P
CN602 1-691-370-11 CONNECTOR, FFC/FPC 6P
CN603 1-816-176-11 FFC/CONNECTOR, FPC (ZIF) 6P
CN605 1-815-031-11 FFC/CONNECTOR, FPC (ZIF) 24P
CN608 1-816-176-11 FFC/CONNECTOR, FPC (ZIF) 6P
CN609 1-816-176-11 FFC/CONNECTOR, FPC (ZIF) 6P
< DIODE >
D602 6-500-941-01 DIODE MAZS056008S0
< FERRITE BEAD >
FB601 1-400-461-21 FERRITE, EMI (SMD) (1005)
< IC >
IC601 8-759-693-13 IC NJM12904V (TE2)
IC602 8-753-229-98 IC CXM3006CR-T4
< COIL >
L601 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L602 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
L603 1-400-588-11 INDUCTOR, LAMINATE CHIP 10uH
< TRANSISTOR >
Q601 8-729-427-52 TRANSISTOR XP4216
Q602 8-729-427-23 TRANSISTOR XP4116-TXE
Q606 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q607 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q608 6-550-234-01 TRANSISTOR UNR32A300LS0
Q609 8-729-041-23 TRANSISTOR NDS356AP
Q610 6-550-232-01 TRANSISTOR 2SA2029T2LQ/R
Q611 8-729-026-53 TRANSISTOR 2SA1576A-T106-QR
Q613 8-729-053-52 TRANSISTOR HN1C01FE-Y/GR (TPLR3)
< RESISTOR >
R605 1-208-855-81 METAL CHIP 47 0.5% 1/16W
R606 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R608 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R609 1-218-975-11 RES-CHIP 68K 5% 1/16W
R613 1-208-934-11 METAL CHIP 91K 0.5% 1/16W
R614 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R615 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R616 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R617 1-218-953-11 RES-CHIP 1K 5% 1/16W
R619 1-208-855-81 METAL CHIP 47 0.5% 1/16W
R620 1-218-965-11 RES-CHIP 10K 5% 1/16W
R623 1-208-855-81 METAL CHIP 47 0.5% 1/16W
R624 1-218-977-11 RES-CHIP 100K 5% 1/16W
R625 1-218-990-11 SHORT CHIP 0
R626 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R627 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R628 1-218-949-11 RES-CHIP 470 5% 1/16W
R634 1-218-989-11 RES-CHIP 1M 5% 1/16W
R636 1-218-990-11 SHORT CHIP 0
R637 1-218-978-11 RES-CHIP 120K 5% 1/16W
R638 1-216-864-11 SHORT CHIP 0
R639 1-216-864-11 SHORT CHIP 0
R642 1-218-973-11 RES-CHIP 47K 5% 1/16W
R643 1-218-973-11 RES-CHIP 47K 5% 1/16W
R644 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R645 1-218-960-11 RES-CHIP 3.9K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB601 1-234-369-21 RES, NETWORK 10 (1005X4)
A-1081-844-A SI-042 BOARD, COMPLETE
**********************
< CAPACITOR >
C602 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C603 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C608 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C610 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C611 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C612 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C613 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C614 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C615 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C616 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C618 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C619 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C621 1-100-252-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
CN601 1-778-507-21 PIN, CONNECTOR (PC BOARD) 4P
CN603 1-766-348-21 CONNECTOR, FFC/FPC 18P
PD-238 SI-042
