118
Quick Reference
Identifying parts and controls
The numbers in ( ) are reference pages.
A Power zoom lever (25, 33)
B PHOTO button (20, 24)
C POWER switch (17)
D CHG (charge) lamp (13)
E CHG (charge)/ (flash) lamp (13, 26)
F (flash) button (26)
G Battery pack (13)
H DC IN jack (13)
I (Movie)/ (Still) mode lamps
(23)
J ACCESS lamp (Hard disk) (23)
K START/STOP button (20, 24)
L Grip belt (19)
M Hooks for a shoulder belt
Attach a shoulder belt (optional).
DCR-SR32E/SR33E/SR42E/SR52E/SR62E/
SR72E/SR82E:
DCR-SR190E/SR200E/SR290E/SR300E:
