Appendixes A-17
Appendixes
The following figures show how to fit
the supplied shoulder belt.
Note
If you fit the shoulder belt incorrectly,
the unit may fall down and cause body
injury. Follow the procedures
described below to fit or remove the
shoulder belt.
∫
Press and pull up.
To remove the shoulder belt
∫
While pressing down the
indication PRESS, move
the clip downwards to
release it.
Attaching the fixing plates
If you want to be able to combine two
units or separate the combined units
without using tools such as
screwdrivers, replace the screws (M3)
that hold the fixing place in place with
the supplied coin screws.
Using the Shoulder Belt
Note
The coin screws (M4) for fixing the
handle have washers. When you
remove the handle, keep the screws
and washers by fastening them to the
handle.
To separate the combined
VTRs
Reverse the steps for combination in a
horizontal position.
To Next Page
