Input and Output Settings for Video and Audio Signals
(Sub LCD Menu)
2-30 Preparations
Chapter 2 Preparations
VID SG
Select the test signal to be output from the VTR’s internal test signal
generator.
The internal test signal generator operates and outputs the selected test
signal. This signal can also be recorded.
CB100 (625 mode) : 100% color bar signal
CB75 (525 mode) : 75% color bar signal
CB75R: 75% color bar signal (reverse)
BOW: Bowtie signal
PLSBR: Pulse & bar signal
MLTBS: Multi-burst signal
HSWP: H sweep signal
5STEP: 5-step signal
RAMP: Ramp signal
SH: Shallow ramp signal
RED: Red signal
GRAY: 50% flat signal
WHITE: 100% flat signal
BB: Black burst signal
SDI: SDI check field signal
NTC7: NTC 7 test signal (selectable only in 525 mode)
LN330: Line 330 test signal (selectable only in 625 mode)
Item
Setting
