Sony DVCAM DSR-PD150 User Manual

6-15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
DD-138D
< RESISTOR >
R255 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R256 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R257 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R258 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R259 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R260 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R261 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R262 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R263 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R264 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R265 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R266 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R267 1-218-969-11 RES-CHIP 22K 5% 1/16W
R268 1-218-969-11 RES-CHIP 22K 5% 1/16W
R269 1-218-969-11 RES-CHIP 22K 5% 1/16W
< SWITCH >
S250 1-771-138-61 SWITCH, KEY BOARD(TITLE)
S251 1-771-138-61 SWITCH, KEY BOARD(DISPLAY)
S252 1-771-138-61 SWITCH, KEY BOARD(MEMORY INDEX)
S253 1-771-138-61 SWITCH, KEY BOARD(TC/U-BIT)
S254 1-771-138-61 SWITCH, KEY BOARD(MEMORY +)
S255 1-771-138-61 SWITCH, KEY BOARD(DIGITAL EFFECT)
S256 1-771-138-61 SWITCH, KEY BOARD(RESET)
S257 1-771-138-61 SWITCH, KEY BOARD(MEMORY -)
S258 1-771-138-61 SWITCH, KEY BOARD(MENU)
S259 1-771-138-61 SWITCH, KEY BOARD(MEMORY DELETE)
S260 1-771-138-61 SWITCH, KEY BOARD(MEMORY MIX)
S261 1-771-138-61 SWITCH, KEY BOARD(DATA CODE)
S262 1-771-138-61 SWITCH, KEY BOARD(MEMORY PLAY)
S263 1-762-648-21 SWITCH, SLIDE(ZEBRA/OFF/70/100)
************************************************************
A-7074-466-A DD-138D BOARD, COMPLETE
************************
(Ref.No.;1000Series)
< CAPACITOR >
C300 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C301 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C302 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C303 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C304 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C305 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C307 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C308 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C309 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C310 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C311 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C312 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C313 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C314 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C315 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C316 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C317 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C318 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C319 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C320 1-164-933-11 CERAMIC CHIP 220PF 10% 16V
C321 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C322 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C323 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C324 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C325 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C326 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C327 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C328 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C329 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C330 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C331 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C332 1-164-940-11 CERAMIC CHIP 0.0033uF 10% 16V
C333 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C334 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C335 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C336 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C337 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C338 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C339 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C340 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C341 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C342 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C343 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C344 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C345 1-127-760-91 CERAMIC CHIP 4.7uF 10% 6.3V
C346 1-127-820-91 CERAMIC 4.7uF 16V
C347 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C349 1-127-820-91 CERAMIC 4.7uF 16V
C350 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C351 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C352 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C353 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C354 1-104-852-11 TANTAL. CHIP 22uF 20% 6.3V
C355 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C356 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C357 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C358 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C359 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C360 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C361 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C362 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C363 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C364 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C365 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C366 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C367 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C368 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C369 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C370 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C371 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C372 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C373 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C375 1-113-985-11 TANTAL. CHIP 10uF 20% 20V
C376 1-135-212-21 TANTAL. CHIP 2.2uF 20% 35V
C450 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
