6-36E
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< SWITCH >
S100 1-571-640-11 SWITCH, SLIDE (CH1 48V)
S102 1-762-824-11 SWITCH, SLIDE (OUTPUT SEL)
S103 1-762-825-11 SWITCH, SLIDE (CH1 SEL)
S104 1-762-825-11 SWITCH, SLIDE (CH2 SEL)
S105 1-571-640-11 SWITCH, SLIDE (CH2 48V)
************************************************************
MISCELLANEOUS
**************
1 1-678-055-21 FP-187 FLEXIBLE BOARD
8 1-678-057-21 FP-189 FLEXIBLE BOARD
14 1-678-067-21 FP-200 FLEXIBLE BOARD
65 1-678-054-21 FP-186 FLEXIBLE BOARD
67 1-678-059-21 FP-191 FLEXIBLE BOARD
74 1-469-830-11 FILTER, EMI (US)
122 1-476-075-21 SWITCH BLOCK, CONTROL (PS-4980)
123 1-476-025-21 SWITCH BLOCK, CONTROL (CF-4980)
153 1-678-063-21 FP-196 FLEXIBLE BOARD
0163 1-418-876-11 TRANSFORMER UNIT, INVERTER
164 1-678-062-11 FP-195 FLEXIBLE BOARD
203 1-960-558-11 HARNESS (CP-094) (14P)
204 1-960-557-11 HARNESS (CP-093) (8P)
205 1-476-183-11 SWITCH BLOCK, CONTROL (ED-4980)
212 1-678-064-21 FP-197 FLEXIBLE BOARD
234 1-678-061-21 FP-194 FLEXIBLE BOARD
267 1-678-049-11 FP-202 FLEXIBLE BOARD
274 1-469-829-11 CORE, FERRITE (US)
276 1-678-051-11 FP-216 FLEXIBLE BOARD
280 1-678-052-11 FP-217 FLEXIBLE BOARD
281 1-678-053-11 FP-218 FLEXIBLE BOARD
307 1-678-058-11 FP-190 FLEXIBLE BOARD
310 1-694-411-11 TERMINAL BOARD, BATTERY
312 1-794-637-11 CONNECTOR, DC-IN
322 1-469-829-11 CORE, FERRITE (US)
356 1-678-060-11 FP-193 FLEXIBLE BOARD
408 1-678-056-21 FP-188 FLEXIBLE BOARD
413 1-960-654-11 HARNESS, CJ-064
454 A-7031-100-A PRISM ASSY (SERVICE)(INCLUDE 3CCD)(US)
454 A-7031-101-A PRISM ASSY (SERVICE)(INCLUDE 3CCD)(AEP)
458 1-758-419-21 LENS, ZOOM (VCL-6012WC)
812 1-657-785-11 FP-248 FLEXIBLE BOARD (DEW SENSOR)
CN901 1-784-723-11 PIN, CONNECTOR 4P
D901 8-719-067-13 DIODE GL453K
H901 8-719-061-28 DIODE HW-105C-FT-V (S REEL)
H902 8-719-061-28 DIODE HW-105C-FT-V (T REEL)
LCD901 8-753-050-52 ACX300CK-J
LCD902 A-7096-156-A PANEL BLOCK ASSY, INDICATION
LCD903 8-753-026-79 LCX033AL-J
M901 A-4900-081-A DRUM ASSY (DEH-14B/J-RP)
M902 8-835-606-01 MOTOR, DC SCD15A/C-NP (CAPSTAN)
M903 X-3948-346-1 MOTOR ASSY, LOADING
0ND901 1-517-931-11 TUBE, FLUORESCENT,COLD CATHODE
Q901 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE END)
Q902 8-729-907-25 PHOTO TRANSISTOR PT4850F (TAPE TOP)
S901 1-771-039-51 SWITCH, PUSH (CASSETTE IN)
S902 1-572-719-32 SWITCH, PUSH (1 KEY) (REC PROOF)
S903 1-771-325-11 ENCODER, ROTARY (SWITCH) (MODE)
SP901 1-529-590-11 SPEAKER (2.0CM)
************************************************************
ACCESSORIES
************
0 1-475-599-11 ADAPTOR, AC (AC-L10)
1-475-950-21 REMOTE COMMANDER (RMT-811)
1-575-334-11 CORD, CONNECTION (AV CABLE)
0 1-690-827-11 CORD SET, POWER (AEP)
0 1-775-843-21 CORD, POWER (WITH FILTER)(AEP)
0 1-790-107-22 CORD, POWER (US)
1-792-826-11 CORD, CONNECTION (USB CABLE)
3-053-056-01 LID, BATTERY CASE
3-060-458-11 MANUAL, INSTRUCTION
(PICTURE GEAR 4.1 LITE)(ENGLISH/RUSSIAN)
3-060-458-21 MANUAL, INSTRUCTION
(PICTURE GEAR 4.1 LITE)(FRENCH/GERMAN)
3-060-458-31 MANUAL, INSTRUCTION
(PICTURE GEAR 4.1 LITE)(ITALIAN/DUTCH)(AEP)
3-060-476-01 PICTURE GEAR 4.1 LITE(SYSTEM DISK)
3-060-676-01 EYE CUP, LARGE
3-060-817-11 MANUAL, INSTRUCTION (ENGLISH)(PD150)
(US)
3-060-817-21 MANUAL, INSTRUCTION (FRENCH)(PD150)
(US)
3-060-817-31 MANUAL, INSTRUCTION (ENGLISH)(PD150P)
(AEP)
3-060-817-41 MANUAL, INSTRUCTION (FRENCH)(PD150P)
(AEP)
3-060-817-51 MANUAL, INSTRUCTION (GERMAN)(PD150P)
(AEP)
3-060-817-61 MANUAL, INSTRUCTION (ITALIAN)(PD150P)
(AEP)
3-061-238-11 MANUAL, INSTRUCTION (MSAC-US1)
(ENGLISH/FRENCH)
3-061-238-21 MANUAL, INSTRUCTION (MSAC-US1)
(GERMAN/SPANISH/DUTCH/SWEDISH/ITALIAN/PORTUGUESE/
RUSSIAN/ARABIC/TRADITIONAL CHINESE/KOREAN/DANISH/
FINNISH)(AEP)
3-061-255-01 SYSTEM DISK (MSAC-US1)
3-062-061-11 MANUAL, INSTRUCTION
(AUTO LOGO INSERT FOR CORYRIGHT PROTECTION)
(ENGLISH/FRENCH/GERMAN/ITALIAN)
3-987-015-01 BELT (S), SHOULDER
A-7033-740-A MEMORY STICK MSA-4A
A-7094-140-A NP-F330 BATTERY PACK (US)
A-7094-141-A NP-F330 BATTERY PACK (AEP)
A-7096-180-A MSAC-US1 MEMORY STICK READER/WRITER
XS-001
Be sure to read “Precautions upon replacing CCD imager”
on page 4-9 when changing the CCD imager.
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
