7
EN
If you have a personal
computer or audio/video
equipment with the
S-Video input
You can connect it to your Color Video Camera
with a commercially available S-video cable.
Notes
• You cannot connect your Color Video Camera to a
personal computer that is not equipped with either audio/
video input or S-Video input jack. And you might not be
able to use your existing personal computer with your
Color Video Camera unless you provide the computer
with a video capture board, sound board, and/or
software. Consult your computer dealer or manufacturer
for details.
• Use only the AC-EV2 (for EVI-D30)/AC-EV3 (for EVI-
D31) AC power adaptor (supplied). Do not use any other
AC power adaptor.
• Do not grasp the camera head when carrying the video
camera.
• Do not turn the camera head manually. Doing so will
result in the camera malfunctioning.
Secure the camera in place with the supplied Velcro
tape.
Installation
Be sure to place the main unit on a flat surface.
If you operate more than one camera
with the remote commander
Notice the CAMERA NO. switch at the rear of the
main unit. Set the CAMERA NO. switch to the
position that is different from the positions to that
of what the other cameras' CAMERA NO. switches
are set.
(See page 11.)
Polarity of the plug
CAMERA NO.
1 2 3
