Sony Handycam DCR-HC28 User Manual

17
Getting Started
Step 5: Using the touch panel
You can play back recorded pictures
(p. 25), or change the settings (p. 34) using
the touch panel.
Place your hand on the rear side of
the LCD panel to support it. Then,
touch the buttons displayed on the
screen.
• If the buttons on the touch panel do not work
correctly, adjust the LCD screen
(CALIBRATION) (p. 70).
• Dots in lines may appear on the LCD screen, but
this is not a malfunction. These dots are not
recorded.
To hide the screen indicators
Press DISP/BATT INFO to toggle the
screen indicators (such as time code) on or
off.
You can change the on-screen displays to
show messages in a specified language.
Select the screen language in [
LANGUAGE] on the (SETUP
MENU) (p. 34, 47).
You can easily check the meaning of each
indicator (p. 29) that appears on the LCD
screen.
1 Touch .
2 Touch [DISP GUIDE].
The indicators vary depending on the
settings.
Touch the button on the LCD screen.
DISP/BATT INFO
Changing the language setting
Checking the screen indicators
(Display guide)
SPOT
FOCUS
FOCUS
MENU FAD ER END
SCH
EXPO–
SURE
SPOT
METER
DISP
GUIDE
PA G E 1 PA G E 2
60min
–:––:––
Select area for guide.
DISP GUIDE
END
Continued ,

Sony Handycam DCR-HC28 Specifications

Imaging

imaging device	1/6" CCD
pixel gross	680K
video actual	340K Pixels

Convenience

steadyshot image stabilization	Yes
minimum illumination	5 Lux
low light capability	NightShot Plus system

Inputs and Outputs

analog audio/video outputs	Yes (Multi A/V)
digital audio/video inputs	Yes (via i.LINK)
digital audio/video outputs	Yes (via i.LINK)

Display

lcd size	2.5"
lcd resolution	123K Pixels
viewfinder resolution	123K Pixels

Optics and Lens

35mm equivalent	44-880mm (4:3), 48-960mm (16:9)
aperture	f1.8-3.1
optical zoom	20X

Power

power consumption	1.8W/2.1W (VF/LCD)
battery type	InfoLITHIUM (NP-FP30)
power requirements	7.2V (battery), 8.4V (AC Adaptor)

Dimensions and Weight

weight	14 oz (420g)
measurements	2 5/8" x 3 1/8" x 4 1/2" (65 x 79 x 113mm)
