Sony Handycam DCR-HC28 User Manual

45
Using the Menu
VCR SET menu
– AUDIO MIX
See page 34 for details on selecting
menu items.
See page 52.
LCD/VF SET menu
– LCD B.L./LCD COLOR/VF B.L., etc
The default settings are marked with B.
See page 34 for details on selecting
menu items.
You can adjust the brightness of the LCD
screen’s backlight. The recorded picture
will not be affected by this operation.
B BRT NORMAL
Standard brightness.
BRIGHT
Brightens the LCD screen.
• When you connect your camcorder to outside
power sources, [BRIGHT] is automatically
selected for the setting.
• When you select [BRIGHT], battery life is
slightly reduced during recording.
You can adjust the color on the LCD screen
with / . The recorded picture
will not be affected by this operation.
AUDIO MIX
LCD B.L. (LCD back light)
LCD COLOR
Low intensity High intensity
Continued ,

Sony Handycam DCR-HC28 Specifications

Imaging

imaging device	1/6" CCD
pixel gross	680K
video actual	340K Pixels

Convenience

steadyshot image stabilization	Yes
minimum illumination	5 Lux
low light capability	NightShot Plus system

Inputs and Outputs

analog audio/video outputs	Yes (Multi A/V)
digital audio/video inputs	Yes (via i.LINK)
digital audio/video outputs	Yes (via i.LINK)

Display

lcd size	2.5"
lcd resolution	123K Pixels
viewfinder resolution	123K Pixels

Optics and Lens

35mm equivalent	44-880mm (4:3), 48-960mm (16:9)
aperture	f1.8-3.1
optical zoom	20X

Power

power consumption	1.8W/2.1W (VF/LCD)
battery type	InfoLITHIUM (NP-FP30)
power requirements	7.2V (battery), 8.4V (AC Adaptor)

Dimensions and Weight

weight	14 oz (420g)
measurements	2 5/8" x 3 1/8" x 4 1/2" (65 x 79 x 113mm)
