Sony HBD-TZ130 User Manual

27
HBD-TZ130
0 151 A-1749-923-A CDM85 (MB) ASSY
0 152 8-820-321-05 OPTICAL PICK-UP BLOCK (KHM-313CAA/C2RP)
153 4-674-137-11 SCREW (PTP2X5)
154 9-885-150-25 FLEXIBLE CABLE (24 CORE)
155 3-088-371-01 BELT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
4-4. DVD MECHANISM DECK SECTION
Note: If the wire (fl at type) was replaced, fold it some as the
wire (fl at type) before replacement.
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
155
151
152
153
153
153
154
153
Ver. 1.1
