SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. TOP COVER
(Page 9)
2-4. CONTROL BOARD,
STANDBY BOARD
(Page 11)
SET
2-2. DOOR
(Page 10)
2-3. FRONT CABINET SECTION
(Page 10)
2-6. MAIN BOARD
(Page 12)
2-5. USB BOARD
(Page 11)
2-7. POWER BOARD
(Page 12)
2-8. DVD MECHANISM DECK SECTION
(Page 13)
2-9. OPTICAL PICK-UP
(Page 13)
