HCD-DX155/DX255
HCD-DX155/DX255
6-18. PRINTED WIRING BOARD – I/O BOARD –
• See page 29 for Circuit Boards Location.
:Uses unleaded solder.
• Semiconductor
Location
Ref. No. Location
IC201 E-4
IC352 D-8
IC353 C-7
IC360 D-5
Q353 E-7
Q354 E-8
Q360 E-10
Q361 C-10
Q362 C-11
C
MAIN BOARD
CN1302
(Page 36)
E
MAIN BOARD
CN507
(Page 36)
B
MAIN BOARD
CN1301
(Page 36)
L
JACK BOARD
CN402
(Page 49)
IC201
IC360
IC353
IC352
2 1
4 3
S VIDEO
(DVD ONLY)
VIDEO
MONITOR OUT
C R /P R
Y
COMPONENT
VIDEO OUT
C
B /P B
L
TV/VCR
R
TUNER
UNIT
AM
COAXIAL
FM75Ω
13
5
1
13
EE
7
1
E
EE
R292R294
R271
R276
R274
R273
R275
R272
13
