HCD-EC98P
11
Note:
Follow the disassembly procedure in the numerical order shown below
.
3-2.
SIDE P
ANEL (L)/(R)
3-3. P
ANEL
(T
OP)
two
screws
(BVTP3
×
10)
two
screws
(BVTP3
×
10)
four
screws
(case3
TP)
side panel (L)
side panel (R)
four
screws
(case3
TP)
panel
(top)
two
claws
two
screws
(BVTP3
×
10)
two
screws
(BVTP3
×
10)
screw
(KTP3
×
10)
screw
(KTP3
×
10)
