HCD-EC98P
51
52
53
54
55
56
56
56
57
58
59
56
56
60
61
not supplied
not
supplied
not supplied
not supplied
(KEY POWER board)
not supplied
(KEY CD board)
not supplied
(JACK HOLD board)
not supplied
(JACK board)
DMP board
64
63
56
62
51 3-276-202-01 KNOB (VOL)
52 3-276-204-01 RING (VOL) (US, CND)
52 3-276-204-21 RING (VOL) (AUS)
53 3-276-201-01 PLATE, ORNAMENTAL (AUS)
53 3-452-117-01 PLATE, ORNAMENTAL (1CD-G) (US, CND)
54 3-276-198-01 WINDOW
55 A-1418-866-A PANEL ASSY, FRONT (AUS)
55 A-1418-867-A PANEL ASSY, FRONT (US, CND)
56 3-087-053-01 +BVTP2.6 (3CR)
57 1-835-338-21 CABLE, FLEXIBLE FLAT (31 CORE)
58 3-297-298-01 SHEET (RM)
59 A-1379-636-A PANEL BOARD, COMPLETE (US, CND)
59 A-1426-098-A PANEL BOARD, COMPLETE (AUS)
60 1-831-774-21 CABLE, FLEXIBLE FLAT (9 CORE)
61 4-225-252-01 CUSHION (FOOT)
62 1-835-336-21 CABLE, FLEXIBLE FLAT (11 CORE)
63 A-1379-815-A DMP BOARD, COMPLETE
64 3-276-209-01 BRACKET (DMPORT)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
7-2. FRONT PANEL SECTION
