HCD-HX50BTR/HX70BTR/HX80R/HX90BTR
11
3-6. LOADING MECHANISM BLOCK
3-7. BASE UNIT (BU-K6BD91UR2-WOD)
screw
(BVTP3
×
8)
two screws
(BV3)
panel (CD)
R
loading mechanism block
screw
(BV3)
DMP board block
two claws
flexible flat cable (5 core)
(CN001)
flexible flat cable (27 core)
(CN202)
insulator
insulator
base unit
(BU-K6BD91UR2-WOD)
insulator
insulator
two springs
(insulator)
two floating screws
two floating screws
floating screw
loading (BK) assy
two springs (insulator)
– Bottom view –
