64
HCD-HX50BTR/HX70BTR/HX80R/HX90BTR
SECTION 8
ELECTRICAL PARTS LIST
A-1243-637-A AMP BOARD, COMPLETE
(HX50BTR/HX80R/HX90BTR)
A-1486-589-A AMP BOARD, COMPLETE (HX70BTR)
********************
< CAPACITOR >
C701 1-126-961-11 ELECT 2.2uF 20% 50V
C702 1-136-497-81 FILM 0.1uF 5% 50V
C703 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
(HX70BTR)
C704 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C706 1-100-717-91 CERAMIC CHIP 1uF 16V
(HX70BTR)
C706 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX50BTR/HX80R/HX90BTR)
C707 1-112-245-21 ELECT 47uF 20% 35V
(HX50BTR/HX80R/HX90BTR)
C707 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
(HX70BTR)
C708 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX70BTR)
C708 1-112-245-21 ELECT 47uF 20% 35V
(HX50BTR/HX80R/HX90BTR)
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX70BTR)
C709 1-112-245-21 ELECT 47uF 20% 35V
(HX50BTR/HX80R/HX90BTR)
C710 1-112-245-21 ELECT 47uF 20% 35V
(HX50BTR/HX80R/HX90BTR)
C711 1-126-767-11 ELECT 1000uF 20% 16V
(HX70BTR)
C712 1-100-717-91 CERAMIC CHIP 1uF 16V
(HX70BTR)
C712 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX50BTR/HX80R/HX90BTR)
C713 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C714 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
(HX70BTR)
C714 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(HX50BTR/HX80R/HX90BTR)
C715 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
(HX70BTR)
C715 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(HX50BTR/HX80R/HX90BTR)
C716 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
(HX70BTR)
C716 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(HX50BTR/HX80R/HX90BTR)
C717 1-125-898-91 CERAMIC CHIP 0.22uF 10% 50V
(HX70BTR)
C717 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(HX50BTR/HX80R/HX90BTR)
C718 1-100-756-91 CERAMIC CHIP 0.047uF 50V
C719 1-100-924-21 ELECT 2200uF 20% 35V
(HX70BTR)
C719 1-137-806-21 ELECT 1800uF 20% 35V
(HX50BTR/HX80R/HX90BTR)
C720 1-131-704-11 FILM 1uF 5% 50V
C722 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C723 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C724 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C725 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C726 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C728 1-131-704-11 FILM 1uF 5% 50V
C729 1-126-767-11 ELECT 1000uF 20% 16V
(HX50BTR/HX80R/HX90BTR)
C730 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C731 1-104-658-91 ELECT 100uF 20% 10V
C732 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C733 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C735 1-126-964-11 ELECT 10uF 20% 50V
C736 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C737 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C738 1-126-964-11 ELECT 10uF 20% 50V
C739 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C740 1-126-923-91 ELECT 220uF 20% 10V
C741 1-126-961-11 ELECT 2.2uF 20% 50V
C742 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C743 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C744 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C745 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C746 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C747 1-104-658-91 ELECT 100uF 20% 10V
C751 1-126-961-11 ELECT 2.2uF 20% 50V
C752 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C753 1-104-658-91 ELECT 100uF 20% 10V
C754 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C756 1-100-717-91 CERAMIC CHIP 1uF 16V
(HX70BTR)
C756 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(HX50BTR/HX80R/HX90BTR)
C757 1-126-964-11 ELECT 10uF 20% 50V
(HX50BTR/HX80R/HX90BTR)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
BR : Brazilian model
CND : Canadian model
E51 : Chilean and Peruvian model
KR : Korean model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifi é.
MX : Mexican model
RU : Russian model
SP : Singapore model
Ver. 1.1
