Note: Follow the disassembly procedure in the numerical order given.
3-2. COVER (TOP), COVER (BACK)
2 cover (top)
3 two screws
(BVTP3 × 8)
3 three screws
(BVTP3 × 8)
5 cover (back)
4 two claws
1 four screws
(case 3 TP2)
3-3. CASE
1 six screws
(BVTP3
× 8
)
2 four screws
(case 3 TP2)
3
3
4
case
2 four screws
(case 3 TP2)
