HCD-FLX9W
9-9. SP RELAY BOARD SECTION
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
451 4-225-252-01 CUSHION (FOOT)
452 A-4753-509-A SP RELAY BOARD, COMPLETE (EXCEPT TH)
452 A-4753-573-A SP RELAY BOARD, COMPLETE (TH)
* 454 3-703-244-00 BUSHING (2104), CORD (EXCEPT E15)
454 3-703-571-11 BUSHING (S) (4516), CORD (E15)
0 455 1-775-786-21 CORD, POWER (EA)
0 455 1-777-071-83 CORD, POWER (SP)
0 455 1-824-818-11 CORD, POWER (WITH CONNECTOR) (TH)
0 455 1-827-226-11 CORD, POWER (E15)
M801 1-763-488-51 FAN, DC
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
451
452
455
454
#1
not supplied
not supplied
M801
#1
#1
#1
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
