HCD-FLX9W
15
3-7. DVD MECHANISM BLOCK
4
two connectors
(CN805, CN806)
6
claw
2
two connectors
(CN702, CN703)
5
two claws
SP RELAY
board
MC board
7
DVD mechanism block
2
connector
(CN905)
2
connector
(CN903)
1
wire (flat type) (11 core)
(CN105)
1
wire (flat type)
(17 core) (CN204)
2
connector
(CN807)
3
six screws
(BVTP3
×
8
2
two connectors
(CN0005, CN7002)
4
two screws
(BVTP3
×
8)
5
DSP board
2
wire (flat type) (19 core)
(CN602)
1
wire (flat type) (9 core)
(CN603)
3
wire (flat type) (11 core
(CN601)
3-8. DSP BOARD
Note: Please turn a DSP/MB/MC boards side down and do not do decomposition work.
