124
HCD-FLX9W
SECTION 9
EXPLODED VIEWS
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference
number in the exploded views are not supplied.
• Accessories are given in the last of the
electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
• Abbreviation
AUS: Australian model
E15 : Iranian model
EA : Saudi Arabia model
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1 3-363-099-71 SCREW (CASE 3 TP2)
2 4-252-019-01 COVER (TOP)
3 4-252-039-11 CASE
4 3-363-099-11 SCREW (CASE 3 TP2)
5 4-252-020-01 COVER (BACK)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
2
3
4
5
not supplied
DSP/GC/ I/F /MC/MB/REGULATOR/TX boards section
mechanical (cassette) deck section
#1
#1
#1
#1
#1
#1
#1
#1
1
not supplied
4
9-1. COVER SECTION
SP : Singapore model
TH : Thai model
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
