HCD-FLX9W
13
3-4. FRONT PANEL ASSY
3
connector
(CN201)
2
wire (flat type) (17 core)
(CN206)
3
two connectors
(CN203, CN208)
3
connector
(CN207)
MC board
1
wire (flat type) (17 core)
(CN109)
6
three connectors
(CN601, CN602, CN808)
4
two claws
1
screw
(BVTP3
×
8)
1
screw
(BVTP3
×
8)
3
screw
(BVTP3
×
8)
2
two ground
terminals
2
two ground
terminals
5
6
connector
(NO803)
DSP boar
d
7
front panel assy
3
two screws
(BVTP3
×
8)
3
screw
(BVTP3
×
8)
