HDR-FX7/FX7E_L2
SPECIFICATIONS
These specifications are extracted
from instruction manual of HDR-FX7.
System
Video recording system (HDV)
2 rotary heads, Helical scanning system
Video recording system (DV)
2 rotary heads, Helical scanning system
Still image recording system
Exif Ver. 2.2*
1
Audio recording system (HDV)
Rotary heads, MPEG-1 Audio Layer -2,
Quantization: 16 bits (Fs 48 kHz, stereo)
transfer rate: 384 kbps
Audio recording system (DV)
Rotary heads, PCM system
Quantization: 12 bits (Fs 32 kHz, stereo 1,
stereo 2), 16 bits (Fs 48 kHz, stereo)
Video signal
NTSC color, EIA standards
1080/60i specification
Usable cassette
Mini DV cassette with the mark
printed
Tape speed (HDV)
Approx. 18.81 mm/s
Tape speed (DV)
SP: Approx. 18.81 mm/s
LP: Approx. 12.56 mm/s
Recording/playback time (HDV)
60 min (using a DVM60 cassette)
Recording/playback time (DV)
SP: 60 min (using a DVM60 cassette)
LP: 90 min (using a DVM60 cassette)
Fast forward/rewind time
Approx. 2 min 40 s (using a DVM60
cassette and rechargeable battery pack)
Approx. 1 min 45 s (using a DVM60
cassette and AC Adaptor)
Viewfinder
Electric viewfinder (color)
Image device
4.5 mm (1/4 type) 3CMOS sensor
Recording Pixels (HDV/DV16:9 still
recording):
Max. 1.20 Mega (1 440 × 810) pixels *
2
Gross: Approx. 1 120 000 pixels
Effective (movie, 4:3):
778 000 pixels
Effective (movie, 16:9):
1 037 000 pixels
Effective (still, 4:3):
778 000 pixels
Effective (still, 16:9):
1 037 000 pixels
Lens
Carl Zeiss Vario-Sonnar T
20 × (Optical), Approx. 30 × (Digital, when
[D.EXTENDER] is set to [ON])
Focal length
f=3.9 ~ 78 mm (5/32 ~ 3 1/8 in.)
When converted to a 35 mm still camera
*
3
37.4 ~ 748mm (1 1/2 ~ 29 1/2 in.) (16:9),
45.7 ~ 914 mm (1 13/16 ~ 36 in.) (4:3)
F1.6 ~ 2.8
Filter diameter: 62 mm (2 1/2 in.)
Color temperature
[INDOOR] (3 200 K),
[OUTDOOR] (5 800 K)
Minimum illumination
4 lx (lux) (F 1.6)
*
1
“Exif” is a file format for still images,
established by the JEITA (Japan Electronics
and Information Technology Industries
Association). Files in this format can have
additional information such as your
camcorder’s setting information at the time
of recording.
*
2
The unique pixel array of Sony's ClearVid
CMOS Sensor and image processing system
(new Enhanced Imaging Processor) allows
for still image resolution equivalent to twice
that of the image sensor's effective pixel
count.
*
3
The focal length figures are actual figures
resulting from wide angle pixel read out.
Output connectors
AUDIO/VIDEO output
10-pin connector
Video signal: 1 Vp-p, 75 Ω (ohms),
unbalanced
Luminance signal: 1 Vp-p, 75 Ω (ohms),
unbalanced
Chrominance signal: 0.286 Vp-p, 75 Ω
(ohms), unbalanced
Audio signal: 327 mV (at load impedance
47 kΩ (kilohms)), Output impedance with
less than 2.2 kΩ (kilohms)
COMPONENT OUT jack
Y: 1 Vp-p, 75 Ω (ohms), unbalanced P
B
/
P
R
, C
B
/C
R
: +/- 350 mVp-p
HDMI OUT jack
TypeA (19-pin)
Input/Output connectors
LANC jack
Stereo mini-minijack (Ø 2.5 mm)
USB jack
mini-B
HDV/DV jack
i.LINK interface (IEEE 1394, 4-pin
connector S100)
LCD screen
8.8 cm (3.5 type, aspect ratio 16:9)
Total dot number
211 200 (960 × 220)
General
Power requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption
During camera recording using the
viewfinder with normal brightness:
HDV recording 5.9 W
DV recording 5.7 W
During camera recording using the
LCD with normal brightness:
HDV recording 5.9 W
DV recording 5.7 W
Operating temperature
0 °C to + 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
145 × 156 × 322 mm
(5 3/4 × 6 1/4 × 12 3/4 in.) (w/h/d)
including the projecting parts
145 × 156 × 322 mm
(5 3/4 × 6 1/4 × 12 3/4 in.) (w/h/d)
including the projecting parts with
batterypack NP-F570
Mass (approx.)
1.4 kg (3 lb 2 oz) main unit only 1.6 kg
(3 lb 10 oz) including the NP-F570
rechargeable battery pack, cassette, and
lens hood with lens cover
Supplied accessories
AC Adaptor (1)
Power cord (1)
Wireless Remote Commander (1)
A/V connecting cable (1)
Component video cable (1)
USB cable (1)
Large eyecup(1)
Rechargeable battery pack NP-F570 (1)
Lens hood with lens cover (1)
Operating Guide (1)
See page 5-41.
AC Adaptor AC-L15A
Power requirements
AC 100 - 240 V, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC 8.4 V*
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Storage temperature
-20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions (approx.)
56 × 31 × 100 mm
(2 1/4 × 1 1/4 × 4 in.) (w/h/d)
excluding the projecting parts
Mass (approx.)
190 g (6.7 oz) excluding the power cord
* See the label on the AC Adaptor for other
specifications.
Rechargeable batterypack NP-F570
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
15.8 Wh (2 200 mAh)
Dimensions (approx.)
38.4 × 20.6 × 70.8mm
(1 9/16 × 13/16 × 2 7/8in.) (w/h/d)
Mass (approx.)
100 g (3.5 oz)
Operating temperature
0 °C to 40 °C (32 °F to 104 °F)
Type
Lithium ion
Design and specifications are subject to change without
notice.
