Sony HDR-FX7 User Manual

4-3. PRINTED WIRING BOARDS
HDR-FX7/FX7E_L2
Link
Link
RR-003 BOARD (SIDE A)
EE-006 BOARD
WW-003 BOARD
II-003 BOARD
PP-003 BOARD
RR-003 BOARD (SIDE B)
UU-003 BOARD
JJ-004 BOARD
FP-482 FLEXIBLE BOARD
FP-481 FLEXIBLE BOARD
FP-486 FLEXIBLE BOARD
FP-484 FLEXIBLE BOARD
FP-031, FP-032, FP-228 FLEXIBLE BOARD
FP-485 FLEXIBLE BOARD
OO-003 BOARD
FP-487 FLEXIBLE BOARD
FP-483 FLEXIBLE BOARD
MM-061 BOARD
MOUNTED PARTS LOCATION COMMON NOTE FOR PRINTED WIRING BOARDS

Sony HDR-FX7 Specifications

General

Built-in display	Yes
Display diagonal	3.5 \
Display resolution (numeric)	211000 pixels
Filter size	62 mm
Digital zoom	- x
Optical zoom	20 x
Focal length range	3.9 - 78 mm
Interchangeable lens	-
Maximum aperture number	2.8
Minimum aperture number	1.6
Focal length (35mm film equivalent)	37.4 - 748 mm
Maximum focal length (35mm film equiv)	748 mm
Minimum focal length (35mm film equiv)	37.4 mm
Sensor type	CMOS
Total megapixels	1.07 MP
Optical sensor size	1/4 \
Camcorder tape type	HDV
Camcorder media type	Videotape
Compatible memory cards	MS PRO
Internal storage capacity	- GB
S-Video in	No
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Focus adjustment	Auto/Manual
Camera shutter speed	1/3 - 1/10000 s
Camcorder type	Shoulder camcorder
Minimum illumination	4 lx
Supported aspect ratios	4:3, 16:9
Product color	Black
Maximum video resolution	1920 x 1080 pixels
Image formats supported	JPG
Maximum image resolution	1440 x 810 pixels
Audio system	stereo
Battery capacity	- mAh
Battery life (max)	8 h
Cables included	AV, USB
Aperture range (F-F)	1.6 - 2.8

Weight and Dimensions

Depth	322 mm
Width	145 mm
Height	156 mm
Weight	1400 g
